Cut Section Model Of Four Stroke Four Cylinder Indirect Injection Diesel Engine Working
Model: BT-03A
Material: Mild Steel
Model Number: BT-03A
Applications: Educational
Type od service provider: Individual Designer
Accuracy: Yes
Phase:: Single Phase
The model is made out of full-size original four-stroke, four cylinders used Diesel engine. Maximum parts and accessories like three cylinders, cylinder head, inlet, and Exhaust manifolds, Fuel Injection pump, oil pump, Water pump, Fuel Filter, Injector, Self-starter, Alternator, etc. are sectioned to show the internal constructional details of the engine. The working of individual parts and accessories like Valves, Pistons, pumps, Crank and Camshaft, etc. can be demonstrated. This model is provided up to Flywheel and the model is mounted on a sturdy iron frame. The model is coupled to F.H.P 220/230V A.C. Motor, through a Reduction gear unit to get the slow speed rotation of the Flywheel and the engine around 15 to20 rpm.
