Petrol Engine with Simulator – BT-02A

Product Overview

The Petrol Engine with Simulator (BT-02A) is a fully functional automotive training unit designed to provide hands-on experience with petrol engine operation, diagnostics, and measurement. Built with a real engine and integrated instrumentation, it is ideal for technical training institutes and workshops.

Engine Specifications

• Engine Type: 4-Cylinder Inline Petrol Engine
• Engine Model: 1NZ-FE
• Engine Displacement: 1497 cc (1.5 L)
• Fuel System: Electronic Fuel Injection (EFI)
• Cooling System: Water Cooled
• Ignition System: Electronic Ignition System
• Maximum Power: Approx. 105–110 HP

Trainer Construction

• Fully functional petrol engine mounted on a heavy-duty tubular steel frame
• Rotatable stand with lockable caster wheels for easy mobility
• Equipped with flywheel guard and radiator guard for safety
• Minimum 3-liter fuel tank with integrated fuel pump

Instrumentation Panel

• Ignition key switch
• Oil pressure gauge
• Water temperature gauge
• Diagnostic terminals for measurement

Measurement & Diagnostic Features

• Enables measurement of electrical signal parameters of sensors and actuators using multimeter and oscilloscope
• Supports measurement of high-voltage ignition system circuits
• Suitable for real-time diagnostics and troubleshooting training

Technical Parameters

• Dimensions (H × L × W): Approx. 1800–1900 × 1000–1100 × 500–510 mm
• Weight: Approx. 150–160 kg
• Power Supply: AC 220V ±10%, 50/60 Hz

Warranty

• 3 Years
