Description

Basic Info

Product Name: Sequential Fuel Injection System

Model: BT-07FIS

Technical Specifications

System Type

• Automotive Sequential Fuel Injection Training System
• Common Rail Electronic Fuel Injection Demonstration Trainer

Fuel Injection System

Injection Details

• Injection Type: Electronically controlled sequential fuel injection
• Fuel System: Common rail high-pressure system

Core Components

• High Pressure Pump: Automotive type high-pressure fuel pump
• Injectors: Minimum 4 electronic injectors
• Fuel Tank Capacity: Minimum 8 liters
• Fuel Filter: Automotive type with fuel pump assembly
• Fuel Pressure Range: 800 – 3000 bar

Electronic Control System

• ECU: Automotive Electronic Control Unit
• Diagnostic Interface: Standard diagnostic socket (OBD compatible)
• Fault Simulation: Built-in fault insertion unit for training purposes

Sensors

• Mass Air Flow (MAF) Sensor
• Rail Pressure Sensor
• Temperature Sensors (Air / Coolant)
• Crankshaft Position Sensor
• Accelerator Pedal Position Sensor
• Fuel Metering Valve Sensor

Actuators

• Electronic fuel injectors
• Fuel pressure control valve
• EGR valve actuator

Structure & Build

• Mounted on heavy-duty steel mobile frame
• Lockable caster wheels for easy movement

Training Panel

Display & Layout

• Silk-screen printed schematic diagram
• Clearly marked system layout

Measurement Terminals

• Voltage
• Current
• Resistance

Power Supply

External Power

• 220V AC ±10%, 50/60 Hz

Internal Power

• 12V DC with overload and short-circuit protection

Safety Features

• Emergency stop switch
• Electrical fuse protection
• Insulated wiring and connectors

Additional Information

• Manufacturer Website: www.bdtrainer.com
• Year of Manufacture: 2026
